LC414 Column Type Load Cell Working Principle Scale Tester Load Cell

Availability:
Quantity:
  • LC414

  • SAINTBOND

Load Cell

LC414

Dimensions Unit:mm

LC414

Cap/Size

D1

D2

D3

H1

H2

F

G

20~50t

87

70

56

138.5

112

35

62

80~150t

120

105

76

200

167

50

78

200t

159

143

108

270

220

70

100



Product Descriptions:

Load cells &weigh modules LC414 is a column, low profile, compression load cell. We can produce the load cell with analog load cells, digital load cells, wireless load cells, stainless steel load cells, alloy steel load cell, high temperature load cell, anti-lighting load cell. The fully leak-tested welded construction, advanced cable entry and built-in surge protection tubes ensure this product can be used successfully in harsh environments. This product meets the stringent weights and measures requirements. This product is suitable for use in road and rail weighbridges and process weighing applications, truck and rail weighbridges, silo and hopper weighing, process weighing and weighing equipment.



Technical Parameter:

Rated Load:

12/3/5/15/20/25/30/40/50t

Operating Temp. Range:

-30~+70℃

Sensitivity:

(2.0±0.1%) mV/V

Max. Safe Over Load:

150%F.S

Combined Error:

±0.02% F.S

Ultimate Over Load:

300%F.S

Creep Error(30min)

±0.02% F.S

Recommend Excitation:

10~12VDC

Zero Balance:

±1% F.S

Maximum Excitation:

15V DC

Temp. Effect On Zero:

±0.02% F.S/10℃

Sealing Class:

IP67/IP68

Temp. Effect On Span:

±0.02% F.S/10℃

Element Material:

-A: Alloy Steel, -SS: Stainless Steel

Input Resistance:

750±5Ω

Cable:

Length=13m

Output Resistance:

702±2Ω

Citation:

GB/T7551-2008/ OIML R60

Insulation Resistance:

≥5000MΩ

Mode Of Connection:

Red(Input+),Black(Input-),

Green(Output+White(Output-)


圣邦网站1详情页_05

Product name LC414 Column Type Load Cell Working Principle Scale Tester Load Cell
Brand SAINTBOND
Market All over the world
Features High precision and stable performance
Advantage 0EM/ODM
Sample Lead Time 5~ 40Days
Sample price The price is different according to product capacity
Custom Design Welcome
Form of sale Factory supply
