LC402M
SAINTBOND
Dimension:
Product Descriptions:
lLC402 load cells are available in the capacities 0.5t to 50t .
lAlloy steel/ Stainless steel construction,hermetically welded,oil-proof, waterproof and anti-corrosive gas and medium making it lightning protected in all kinds of environments.
lColumn structure, anti-reversal design,good self-aligning ability,suitable for electronic platform scales, automobile testing facilities,hopper scales and other electronic weighing devices.
lSafe and anti-explosive product,can be used in atrocious environment and hazardous areas.
Technical Parameter:
Rated Load: | 10/20/30/40/50t | Operating Temp. Range: | -30~+70℃ |
Sensitivity: | (3.0±0.1%) mV/V | Maximum Safe Over Load: | 150%F.S |
Combined Error: | ±0.05% F.S | Ultimate Over Load: | 250%F.S |
Creep Error(30min): | ±0.02% F.S | Recommend Excitation: | 10~12V DC |
Zero Balance: | ±1% F.S | Maximum Excitation: | 15V DC |
Temp. Effect On Zero: | ±0.02% F.S/10℃ | Sealing Class: | IP67/IP68 |
Temp. Effect On Span: | ±0.02% F.S/10℃ | Element Material: | Alloy /Stainless Steel |
Input Resistance: | 750±5Ω | Cable: | Length=15m |
Output Resistance: | 702±2Ω | Citation: | GB/T7551-2008/ OIML R60 |
Insulation Resistance: | ≥5000MΩ | Mode Of Connection: | Red(Input+),Green(Output+), Black(Input-),White(Output-) |
| Product name | LC402M Rocker Column Load Cell Compression Column Type Load Cells |
| Brand | SAINTBOND |
| Market | All over the world |
| Features | High precision and stable performance |
| Advantage | 0EM/ODM |
| Sample Lead Time | 5~ 40Days |
| Sample price | The price is different according to product capacity |
| Custom Design | Welcome |
| Form of sale | Factory supply |
