LC2420 Loadcell S Type Manufacturer Mini Load Cells

Availability:
Quantity:
  • LC2420
  • SAINTBOND

Load Cell

LC2420-1

The product is made of alloy aluminum. It is hermetically sealed with glue to IP65, surface anodized and anti-corrosion, integral structure and easy installation.

 Dimension:

LC2420

Technical Data:

Capacity:2-10kg

Material:Aluminum

Precision : C1

 Temp. effect on span(%F.S/10): ±0.05

Comprehensive error(%F.S) : ±0.05

 Temp. effect on zero(%F.S/10) : ±0.05

Rated output(mv/v) : 1.0±0.2-15

 Compensated temp. range( ) : -10+40

Creep(%F.S/30min) : ±0.03

 Use temp. range( ) : -20+60

Zero balance(%F.S) : ±1.0

 Excitation voltage(V) : 10(DC)

Input resistance(Ω) : 1000±10

 Safe overload (%F.S) : 120

Output resistance(Ω) : 1000±3

 Ultimate overload (%F.S) : 150

Insulation resistance(MΩ) : ≥5000(100VDC)

 Defend grade : IP65

LC2420-1圣邦网站1详情页_05

Product name LC2420 Loadcell S Type Manufacturer Mini Load Cells
Brand SAINTBOND
Market All over the world
Features High precision and stable performance
Advantage 0EM/ODM
Sample Lead Time 5~ 40Days
Sample price The price is different according to product capacity
Custom Design Welcome
Form of sale Factory supply
