LC113
SAINTBOND
Dimensions Unit: mm(inch):
Cap./Size | A | B | C | D | øE | øF | RG | RH |
50~150klb | 260.35 (10.25) | 215.9 (8.50) | 76.2 (3.00) | 55.88 (2.20) | 52.32 (2.06) | 60.96 (2.40) | 25.4 (1.00) | 25.4 (1.00) |
200klb | 304.8 (12.00) | 254 (10.00) | 86.36 (3.40) | 63.5 (2.50) | 59.69 (2.35) | 69.85 (2.750) | 38.1 (1.50) | 38.1 (1.50) |
Products Specification
◎LC113 load cell are available in the capacities 50Klb to 200Klb.
◎Steel construction, potted by adhesive inside,oil-proof,waterproof and anti-corrosive gas and medium making it suitable for all kinds of environments.
◎Dual shear beam and they are suitable for truck scales,hopper scales and other electronic weighing devices.
Technical Parameter:
Rated Load: | 50/60/100t(50/60/65/75/100/125/150Klb | ||
Sensitivity: | (3.0±0.1%) m V/V | Operating Temp. Range: | -30~+70℃ |
Combined Error: | ±0.03% F.S | Max. Safe Over Load: | 150%F.S |
Creep Error(30min): | ±0.02% F.S | Ultimate Over Load: | 250%F.S |
Zero Balance: | ±1% F.S | Recommend Excitation: | 10~12V DC |
Tco: | ±0.02% F.S/10℃ | Maximum Excitation: | 15V DC |
Tc Span: | ±0.02% F.S/10℃ | Sealing Class: | IP67/IP68 |
Input Resistance: | 750±5Ω | Element Material: | A:Alloy Steel, SS:Stainless Steel |
Output Resistance: | 703±2Ω | Cable: | Length=L:12m |
Insulation Resistance: | ≥5000MΩ | Citation: | GB/T7551-2008/ OIML R60 |
| Product name | LC113 Zemic Compression Load Cell Stainless Steel Double Shear Beam Load Cell |
| Brand | SAINTBOND |
| Market | All over the world |
| Features | High precision and stable performance |
| Advantage | 0EM/ODM |
| Sample Lead Time | 5~ 40Days |
| Sample price | The price is different according to product capacity |
| Custom Design | Welcome |
| Form of sale | Factory supply |
