H8C
SAINTBOND
Short Description:
◎Nickel plated alloy steel IP67 shear beam load cell; ◎Adhesive sealed;
◎(100 kg, 250kg are bending beam load cells); ◎High accuracy;
◎Suitable platform weighing, bed weighing, etc; ◎High reliability;
◎Current calibrated (sc-option);
Available models:
Capacity | Accuracy | Full article description | Capacity | Accuracy | Full article description |
100kg | C3/C4/C5 | H8C-C3/C4/C5-100kg-4B(-SC-W6) | 2t | C3/C4/C5 | H8C-C3/C4/C5-2t-4B(-SC-W6) |
250kg | C3/C4/C5 | H8C-C3/C4/C5-250kg-4B(-SC-W6) | 2.5t | C3/C4/C5 | H8C-C3/C4/C5-2.5t-4B(-SC-W6) |
500kg | C3/C4/C5 | H8C-C3/C4/C5-500kg-4B(-SC-W6) | 3t | C3/C4/C5 | H8C-C3/C4/C5-3t-4B(-SC-W6) |
1t | C3/C4/C5 | H8C-C3/C4/C5-1t-4B(-SC-W6) | 5t | C3/C4/C5 | H8C-C3/C4/C5-5t-4B(-SC-W6) |
1.5t | C3/C4/C5 | H8C-C3/C4/C5-1.5t-4B(-SC-W6) | 10t | C3/C4/C5 | H8C-C3/C4/C5-10t-4B(-SC-W6) |
Specification:
Accuracy class | OIML R60 C3 | OIML R60 C4 | OIML R60 C5 | ||
Output sensitivity ( = FS ) | mV/V | 3.0 ± 0.003, 2.0 ± 0.002 | |||
Maximum capacity ( Emax ) | t | 0.1,0.25,0.5,1,1.5,2,2.5,3,5,10 | 0.1,0.25,0.5,1,1.5,2,2.5 | 3,5,10 | |
Maximum number of load cell intervals ( nLC ) | 3000 | 4000 | 5000 | ||
Ratio of minimum LC verification interval Y = Emax / vmin | 10 | 15 | 20 | 18 | |
Combined error | %FS | ± 0.023 | ± 0.0175 | ± 0.014 | |
Minimum dead load | kg | 0 | |||
Safe overload | of Emax | 150 % | |||
Ultimate overload | of Emax | 300 % | |||
Zero balance | %FS | ± 1.0 | |||
Excitation, recommended voltage | V | 5 ~ 12( DC ) | |||
Excitation maximum | V | 18( DC ) | |||
Input resistance | Ω | 350 ± 3.5 | |||
Output resistance | Ω | 350 ± 3.5 | |||
Insulation resistance | MΩ | ≥ 5000 ( 50VDC ) | |||
Compensated temperature | ℃ | -10 ~+40 | |||
Operating temperature | ℃ | -35 ~ +65 | |||
Storage temperature | ℃ | -40 ~ +70 | |||
Element material | Nickel plated alloy steel | ||||
Recommended torque on fixation | N.m | M12: 100 M18:200 M24:700 | |||
Ingress protection (according to EN 60529) | IP67 | ||||
ATEX classification (optional) | II1G Ex ia IIC T4 | II1D Ex iaD 20 T73℃ | II3G Ex nL IIC T4 |
Dimensions in mm:
Dimension | L | L1 | L2 | L3 | L4 | H |
1t-2t | 130.00(5.12) | 15.80(0.62) | 25.40(1.00) | 76.20(3.00) | 54.20(2.13) | 31.80(1.25) |
1K-4K | 130.00(5.12) | 15.80(0.62) | 25.40(1.00) | 76.20(3.00) | 54.20(2.13) | 31.80(1.25) |
5KSE | 130.00(5.12) | 15.80(0.62) | 25.40(1.00) | 76.20(3.00) | 31.80(1.25) | 31.80(1.25) |
2.5t-5t | 171.50(6.75) | 19.10(0.75) | 38.10(1.50) | 95.30(3.75) | 77.20(3.04) | 38.10(1.50) |
5K-10K | 171.50(6.75) | 19.10(0.75) | 38.10(1.50) | 95.30(3.75) | 77.20(3.04) | 38.10(1.50) |
10t | 222.30(8.75) | 25.40(1.00) | 50.80(2.00) | 120.70(4.75) | 101.60(4.00) | 50.80(2.00) |
20K | 222.30(8.75) | 25.40(1.00) | 50.80(2.00) | 120.70(4.75) | 101.60(4.00) | 50.80(2.00) |
Dimension | L | L1 | L2 | L3 | L4 | H | H1 | W | W1 | D | d | M |
500kg | 130 | 15.8 | 25.4 | 76.2 | 54.2 | 31.8 | 15.8 | 31.8 | 34 | 13.5 | 13.5 | M12×1.75 |
(5.12) | (0.62) | (1.00) | (3.00) | (2.13) | (1.25) | (0.62) | (1.25) | (1.34) | (0.53) | (0.53) |
Dimension | H1 | W | W1 | D | d | M |
1t-2t | 15.80(0.62) | 31.80(1.25) | 34.00(1.34) | 13.50(0.53) | 13.50(0.53) | M12×1.75 |
1K-4K | 15.80(0.62) | 31.80(1.25) | 34.00(1.34) | 13.50(0.53) | 13.50(0.53) | 1/2-20UNF |
5KSE | 15.80(0.62) | 31.80(1.25) | 34.00(1.34) | 13.50(0.53) | 13.50(0.53) | 1/2-21UNF |
2.5t-5t | 18.80(0.74) | 38.10(1.50) | 40.00(1.57) | 19.80(0.78) | 19.80(0.78) | M18×1.5 |
5K-10K | 18.80(0.74) | 38.10(1.50) | 40.00(1.57) | 19.80(0.78) | 19.80(0.78) | 3/4-16UNF |
10t | 25.40(1.00) | 50.80(2.00) | 52.40(2.06) | 26.90(1.06) | 26.00(1.02) | M24×2 |
20K | 25.40(1.00) | 50.80(2.00) | 52.40(2.06) | 26.90(1.06) | 26.00(1.02) | 1-12UNF |
Wiring:
◎Shielded, 4 conductor cable;
◎Cable diameter: Φ5mm;
◎Standard cable length for 100kg - 2t: 4m and 6m for the higher capacities;
◎Shield in not connected to the element;
